A single connection architecture across implant diameters.
- One prosthetic platform across implant diameters
- Internal hex Ø2.25mm implant–abutment connection
- Reverse active threads
- 12-degree Morse taper
i-Fix Product portfolio
One system,
eight series.
Bone-level, one-piece, compressive and zygomatic implants built around a shared engineering standard — matched to their own sizes, surgical kit and drilling protocol.
01 Implant features
Core features of
every i-Fix implant.
Four core features of every i-Fix implant, reviewed one at a time — open a feature to see the geometry it produces.
Variable thread design from the coronal to the apical region.
- Active thread design
- Coronal back-taper
- Twin cutting flutes ease insertion and bone transfer
A tapered profile designed around the anatomy of a tooth root.
- Self-tapping design
- Flat tip for engagement
- All diameters placed using the i-Fix surgical kit
A closer view of the implant surface treatment.
- Nano bioactivated implant surface
- Macro-rough surface appearance
- Refer to the current IFU for complete specifications
02 Products
Implant systems for
distinct clinical workflows.
Open any product for a quick overview here, or go straight to its full page for sizes, restorative components, surgical kit and documentation.
03 Implant portfolio
Size matrix across
6 implant series.
Select a series to review its catalog-listed diameter × length matrix with article codes. Select any code to copy it. Technical selection remains subject to the applicable catalog and IFU.
Bone-level implant system
IP Series
Also known as i-Fix Pro
Diameter options5
Length range7.5–20 mm
Article codes32
Ø (mm) 7.58.51011.513151820
Ø 3.5 —
Ø 4.0
Ø 4.5 ——
Ø 5.0 ——
Ø 5.5 ———
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Bone-level implant system
SP Series
Also known as S-Fix Pro
Diameter options5
Length range7.0–14 mm
Article codes24
Ø (mm) 7.08.0101214
Ø 3.6 —
Ø 4.0
Ø 4.5
Ø 5.0
Ø 6.0
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Progressive thread implant system
AK Series
Also known as Apex Konnect.webp)
Diameter options3
Length range7.0–13 mm
Article codes11
Ø (mm) 7.09.01113
Ø 3.5 —
Ø 4.2
Ø 5.0
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Bicortical implant
B Series
Also known as i-Fix One
Diameter options1
Length range8–26 mm
Article codes8
Ø (mm) 810121417202326
Ø 3.6
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Compressive implant
C Series
Also known as i-Fix C-1
Diameter options5
Length range8–20 mm
Article codes27
Ø (mm) 8101214161820
Ø 3.5
Ø 4.0
Ø 4.5 ——
Ø 5.0 ———
Ø 5.5 ———
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Zygomatic implant system
ZE Series
Also known as i-Fix Zygon
Diameter options1
Length range30–62.5 mm
Article codes12
Ø (mm) 30354042.54547.55052.55557.56062.5
Ø 4.6
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). Select a code to copy it.
Why i-Fix
Built on one
engineering standard.
Every series in the i-Fix portfolio — bone-level, one-piece, compressive or zygomatic — is held to the same four commitments before it reaches a surgical tray.
Primary Stability
Expanding tapered bodies and variable thread geometry engineered for immediate anchorage.
Biocompatible Titanium
ASTM F136 ELI Grade 5 titanium alloy across the portfolio, built for long-term osseointegration.
Nano-Activated Surface
A Nano Bio Activated surface treatment designed to support faster, more predictable healing.
Restorative Precision
A shared connection architecture that keeps prosthetic workflow consistent, series to series.
04 Surgical protocols
Series-matched
osteotomy workflows.
Drilling sequences and surgical kits are presented directly from the current product catalog, without generated speed or torque values.
IP Series · M1.6 connection
IP Series drilling protocol
Catalog drilling sequence for Ø 3.5–5.5 mm IP Series implant diameters.
Tap to enlarge SP Series · M2.0 connection
SP Series drilling protocol
Catalog drilling sequence for Ø 3.6–6.0 mm SP Series implant diameters.
Tap to enlarge AK Series · progressive thread
AK Series surgical kit
Catalog surgical kit for AK Series Ø 3.5–5.0 mm implant diameters.
Tap to enlarge B & C Series · one-piece
B & C Series surgical kit
Catalog surgical kit for the one-piece B (bicortical) and C (compressive) series.
Tap to enlarge ZE Series · zygomatic
ZE Series surgical kit
Catalog surgical kit for the ZE zygomatic implant series, 30–62.5 mm lengths.
Tap to enlarge Clinical noticeRefer to the applicable product catalog and IFU for the complete drilling protocol, precautions and instrument instructions. Final treatment planning remains the responsibility of the qualified clinician.
06 Frequently asked
Questions clinicians
ask most.
Eight implant series — IP (i-Fix Pro), SP (S-Fix Pro), AK (Apex Konnect), B (i-Fix One), C (i-Fix C-1) and ZE (i-Fix Zygon) in full production detail, with IP+ and AK* upcoming. Plus PSI patient-specific solutions and the Crown digital restorative laboratory.
The one-piece B (i-Fix One) and C (i-Fix C-1) series are built for immediate stabilization and loading — see each series' indications and drilling protocol on its own product page.
The size matrix on each series' product page lists every diameter × length combination with its catalog article code — select a code to copy it.
Open any product model in the grid above — the surgical kit, drilling protocol, catalog and Instructions for Use are all in its Kit & Documentation section.
Yes. IP and AK share one component set, SP has its own K-prefixed set, and ZE has a dedicated zygomatic set — each product page lists every component with its article code.
Upcoming expansions of the IP and AK lines. Their product pages are live with placeholders — full specifications, sizes, images and logos are being finalised by the product team.
Compare specifications across all eight series side by side →
Need the catalog or IFU for a specific series?
Every document is available on request, with its real scope and revision intact.
